11
Contents
1. Technical Data for Märklin Transformers 11
2. Safety Information for the Operation
of Märklin Transformers 12
3. Connecting the Transformer 14
4. Operations with the Transformer 18
Explanation of the symbols used throughout this manual
Important.
Pay close attention.
Otherwise the user may be in danger or,
Components may be damaged.
Item No. 60052 66181
Input voltage 230 volts AC 230 volts AC
50/60 Hz 50/60 Hz
Output voltage 16 volts AC 18 V (=)
Output current < 3.75 amps < 1 A
Power output 60 VA max. 18 VA
1. Technical Data for Märklin Transformers
