6. Install the tongue clamp bolt and brace and front tongue tie down bolt (if required). This
bolt is the 100 x 10mm and is used if the customer does not want to use the tilt function of
the trailer. This is a requirement when using the trailer to carry 50” SXS/UTV due to the
weight of the machines. Optional SXS/UTV ramps must be used in place of the tilt option.
7. Attach the coupler to the tongue and the safety chains at the same time. Use the coupler
mounting bolts, 80 x 10mm. The center link of the safety chain slides through the front
bolt. Torque to 95 ft/lbs.
OWNER’S MANUAL / www.marlonproducts.com
