7. TECHNICAL DATA
Connections
HDMI input 4 x HDMI (19-pin female)
HDMI output 2 x HDMI (19-pin female)
HDMI cable length max. 15 metres
Video
Supported resolutions 480p, 576p, 720p, 1080i, 1080p and 4k2k@24/30
HDMI standards HDCP, CEC, EDID, DVI, all 3D formats, Deep
Color (36-bit), x.v.Color
Video Bandwidth 10.2Gbps
Clock frequency 300MHZ
Audio
HDMI audio DTS-HD Master Audio, Dolby TrueHD, LPCM 7.1,
DTS, Dolby-AC3 and 2.0CH
Switcher housing
Dimensions (H x W x D) 85 x 192 x 26mm
Weight 450 g
Environment
Ambient temperature +0 to +70° C
Ambient humidity 10% to 85%
Power
External power adapter 100-240VAC @50-60Hz, 5VDC @ 1A
Specifications may change without prior notice.
