• Check whether your HDMI sources and screen support HDCP (High-bandwidth
Digital Content Protection).
Do you have a question that has not been answered here? Then have a look at
www.marmitek.com
6 TECHNICAL DATA
Resolution
Supported HDTV Resolutions 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Supported PC Resolution (max.) 1920x1200
Maximum Pixel Frequency (max.) 165MHz
Single link Bit Rate (max.) 1.65Gbps
Video Data Rate (max.) 4.95Gbps
Output Video HDMI 1.2a + HDCP1.0/1.1
Inputs and outputs
HDMI Input (19-pin female) 1 HDMI (gold plated)
HDMI Output (19-pin female) 2 HDMI (gold plated)
Maximum HDMI cable length 15m
Splitter housing
Dimensions (HxWxD) 86x44x16mm
Weight 42g
Environment
Ambient temperature +0 to +70°C
Ambient humidity 10% up to 85%
Power
External power adapter Input: 100-240VAC @50-60Hz
Output: 5VDC @ 2A
Specifications may be modified without prior notice.
5SPLIT312
™
