3
Page
7-1545 7-1546
Fits Boats Up to 20 ft Up to 20 ft
Input Voltage DC 12V DC 12V
Max Working Load 265lb (120kg) 265lb (120kg)
Typical Working Load 45lb (20kg) 45lb (20kg)
Retrieval Speed 57ft(17m)/min 57ft(17m)/min
Pay-Out Speed 73ft (22m)/min Free Fall or
57ft(17m)/min
Continuous Working Time 15 min. 15 min.
Current Draw (Typical) 12 amp 12 amp
Motor Type Permanent Magnet Permanent Magnet
Motor Wattage I/O 600W / 250W 600W / 250W
Motor Efficiency 74% 74%
Gear Type/Efficiency Worm / 50%~88% Worm / 50%~88%
Chain Size 1/4” (7mm) G4 HT 1/4” (7mm) G4
HT
Rope Size 1/2” (12mm)
3 Strand
Medium Lay
1/2” (12mm)
3 Strand
Medium Lay
Dimensions
(L x W x H)
9” x 4.75” x 5.3”
(230x120x135mm)
9” x 4.75” x 5.3”
(230x120x135mm
)
Weight 8.8lb (4.0kg) 10.6lb (4.8kg)
Section III
Specifications:
