13
4, 1
CURRENT SENSE
FAULT
current sense fault
1. Short in motor or in motor wiring.
2. Controller failure.
4, 2 HW FAILSAFE
motor voltage fault
(hardwarefailsafe)
1. Motor voltage does not correspond
tothrottle request.
2. Short in motor or in motor wiring.
3. Controller failure.
4, 3 EEPROM FAULT EEPROM fault 1. EEPROM failure or fault.
4, 4
POWER SECTION
FAULT
power section fault
1. EEPROM failure or fault.
2. Short in motor or in motor wiring.
3. Controller failure.
LED code example:1,4 denotation LED flash a time first, pause several seconds and continue flash 4 times
