SWING. Press Swing button, the appliance will oscillate automatically for wide spread air distribution; press the Swing button again, the appliance will stop oscillation.
MODE. Press the MODE button on the remote control, you can select 3 wind modes; normal, natural & sleep mode.
ANION. Press Anion button, the appliance will start the Anion function to purify the air; press the Anion button again, the appliance will stop Anion function.
COOL.Once you select your fan speed, press the Cool button, this will begin the water circulation and begin the cooling/humidifying/air purifying process.
1. Turn the lock lever of water tank to a horizontal position, carefully pull out the water tank, then pour fresh water into the water tank in order to fill the internal water tank
with water.
2. Check the water level carefully, stop filling when the water level reaches the ‘MAX’ mark.
DO NOT overfill the water tank otherwise permanent damage may occur to the appliance.
3. Check the water level during use to ensure that it does not fall below the ‘MIN’ mark and top up if necessary.
4. To enhance the cooling function, fill the Ice Bottles, replace the top and freeze them in the freezer. Once frozen, place one ice bottle into water tank to cool the water further.
Two ice bottles are supplied so that one can be in water tank cooling the water whilst the other is being frozen and then swapped over when the one in the water tank has defrosted.
Ice box can store cool and slowly absorb the heating from water while ice boxes can make the temperature of water in the water tank less than it of the surrounding, so air
cooler with frozen ice boxes can blow the cooler wind.
NOTICE: please take and put the ice boxes lightly, in order not to hurt the water recycling cooling system.
NOTICE: do not eat ice crystals in the box, and do not use the ice crystal box as a toy for children to prevent accidental ingestion.
5. Press the Cool Button and press the Fan Speed Button to select either the high, medium, or low fan speed.
DO NOT operate in the Cool mode without water in the internal water tank otherwise permanent damage may occur to the unit.
Remote control You can operate the fan by remote control.
The remote control uses 2xAAA battery (not included).
NOTE: the remote control must be pointed towards the receiver on the unit
Please take out the battery for long time no use.
CLEANING AND MAINTENANCE
Emptying the water tank:First turn off and unplug the unit. Place the unit either outside near a drain or alternatively on the sink drainer. Turn the lock lever of water tank to a horizontal position, then
carefully pull out the water tank.You can tilt the unit at several angles to make sure all water is drained out from the unit. When all the water is drained out you can put back the water tank and turn the lock
lever of water tank back to a vertical position to secure the water tank.Take care not to tilt the unit over when full of water.
Cleaning the unit:First turn off and unplug the unit. Wipe the unit housing with a neutral cleaner and a damp soft cloth. Use a dry cloth to dry off the unit. Make sure unit is fully dry before using the unit.
Important :When clean the unit, the client must pull off the plug and cut off the power while any part of control panel cannot be into water.
Cleaning the cooling pad:Remove the cooling pad from the rear cover. Wash the cooling Pad in clean, fresh water; carefully remove any debris using a soft brush. Dry it thoroughly before replacing.
Once the cooling pad is dry, replace it inside the rear cover. Ensure that cooling pad is the correct way up. Replace the filter assembly into the rear of the unit
DO NOT use the appliance without the filter assembly in place. When cleaning the appliance, the client must pull off the plug and cut off the power while any part of control panel cannot be into
water.
SPECIFICATION
Power supply
Producer: Cosmos Far View International Limited
Room 701, 16 apt, Lane 165, Rainbow North Street , Ningbo, China Made in China
WARRANTY DOES NOT COVER SUPPLIES (filters, ceramic and non-stick coating, rubber seals, etc.)
