Martin DC2500e - Installation Options and Components

MARTIN SIDE-MOUNT OPENER INSTALLATION
- May be mounted right side or left side -
WARNING! For Martin Finger Shield Garage Door Systems only.
TORSION SPRING
OPENER DOOR BRACKET
STRAIGHT AND CURVED
POWER ARM
“L” STRUT
EMERGENCY
RELEASE
TAG
EMERGENCY
RELEASE
CORD
KNOB
TOP DOOR SECTION
LIGHT
LENS
POWER
HEAD
POWER
HEAD
CHASSIS
“C”
BRACKETS
OPTIONAL
PUNCHED ANGLE
RAIL SUPPORT BRACKET
RAIL ASSEMBLY
BELT OR CHAIN
TROLLEY
OPENER HEADER BRACKET
END STOP WITH CLEVIS
PIN AND COTTER RING
TORSION TUBE
COPYRIGHT © 2003 MARTIN DOOR
2
TOP ROLLER BRACKET
OPENER DOOR BRACKET
3/8” X 1” SHORT NECK
CARRIAGE BOLT AND
3/8” LOCK NUT
3/8” X 1” SHORT NECK
CARRIAGE BOLT AND
2- 3/8” LOCK NUTS
TOP DOOR SECTION
OPENER HEADER
BRACKET
END STOP WITH CLEVIS
PIN AND COTTER RING
EYE
OPENER DOOR BRACKET
“L” STRUT (IF PROVIDED)
END
STILE
TOP ROLLER
BRACKET
OPENER DOOR BRACKET
3/8” LOCK NUTS
3/8”x1”
SHORT
NECK
CARRIAGE
BOLT
CURVED
POWER ARM
OPENER POWER ARM MUST BE FASTENED
OUTSIDE THE OPENER DOOR BRACKET
WALL
CONTROL
OR
PUSH
BUTTON
“L” STRUT
