GENERAL SAFETY INFORMATION: Always read before proceeding.
Warning
These instructions contain both information and warnings that are
necessary for the safe operation and maintenance of this product. It
is recommended that you read the instructions carefully and ensure
that the contents are fully understood. Failure to understand and to
comply with the warnings and instructions can result in serious
injury, damage or even death.
In order to avoid the danger of electrical shock, it is important that
proper safety measures are taken when working with voltages
exceeding 30V AC RMS, 42V AC peak or 60V DC.
This product must only be used by a competent person capable of
interpreting the results under the conditions and for the purposes for
which it has been constructed. Particular attention should be paid to
the Warnings, Precautions and Technical Specifications. Always
check the unit is in good working order before use and that there are
no signs of damage to it. Do not use if damaged.
Where applicable other safety measures such as use of protective
gloves, goggles etc. should be employed.
Please keep these instructions for future reference. Updated
instructions and product information are available at:
www.martindale-electric.co.uk/instruct
REMEMBER: SAFETY IS NO ACCIDENT
MEANING OF SYMBOLS:
Equipment complies with relevant EU Directives
AC (Alternating Current)
Caution - refer to accompanying documents
Caution - risk of electric shock
End of life disposal of this equipment should be
in accordance with relevant EU Directives
Fuse Check
Test voltage: 4V DC (into open circuit)
Test current: 200mA DC (into short circuit)
Pass level: >2mA
Simulated Load Test
Test voltage: 4V DC (into open circuit)
Test current: 200mA DC (into short circuit)
Accuracy (referenced to 230V rms):
± (5% reading + 2 digits)
Threshold for 'Simulated Current Hi': 16A
Memory
Completed test types that can be stored: 200
General
Overload protection: 300V AC/DC
Protection class: IP20
Safety: Complies to BS EN 61010-1: 2001
Temperature Range: -10 to 40°C, non-condensing
Batteries: 6 x 1.2V AA NiMH rechargeable batteries
1800mAh, or greater
Caution - use only the battery type specified
Battery Life: Fully charged, minimum 600 complete
tests, stored to memory. The HPAT600 will operate fully
from the battery charger in the event of discharged
batteries
Battery Charger:
Input: 230V 50Hz
Output: 12VDC at 300mA, 5.5 jack x 2.5 bore centre
positive
Auto Power Down:
After 10 minutes of inactivity, or when battery low
Dimensions: 90 x 210 x 54mm
Weight: Approx 700g (including batteries & leads)
