SHELVING CONFIGURATIONS
Beverage center:
Loading Tips and Suggestions
Your beverage center is equipped with a cantilever shelf
system which provides maximum adjust ability and custom-
izing of the shelving arrangements listed below.
24" (61 cm) Wide Models:
Shown with a glass door. Figure 12.
(2) perforated metal
cantilever shelves.
(See Figure 13).
Figure 13
Perforated metal shelf
To Add or Remove a Shelf
Remove stored product from the shelf. Do not try to remove
a loaded shelf from the beverage center. Grasp the shelf
front with both hands, rotate the front upward and lift out.
(See Figure 14). To install a shelf insert the shelf in the ap-
pliance and insert the top hooks into the shelf support slots
and drop the shelf down so the hooks drop over the bottom
of the slots.
Make sure your cantilever shelf is secure on the shelf sup-
ports by pressing down on the shelf before loading.
!
CAUTION
!
CAUTION
Never try to move a loaded shelf, remove everything from
the shelf before moving. Use both hands when moving the
shelf.
Rear tang
(hook) on
shelf
Shelf support
slot
Installed shelf
tang
Figure 14a
Figure 14
