21
Figure 42
Dog ears on keg
Figure 42a
Rotate the top of the coupler coun-
ter clockwise to extend the coupler
to the to the "OFF"position.
Coupler
extended
9. Hooking up the keg coupler to the keg: Verify the cou-
lugs on the keg with the corresponding openings on the
keg coupler and turn clockwise until the coupler stops
clockwise to allow gas to enter the keg.
Figure 41
Chain-The chain is fastened and taped
to the top of the interior liner. Remove
the tape and secure the gas tank in
place in the back right corner. Loop
chain around top of tank and connect
with "S" hook.
Push faucet handle back toward
tower to close the faucet
Figure 41a
Connect
with "S"
hook
USING YOUR BEVERAGE DISPENSER
