24
Figure 48
Drain kit (All Models): The drain kit is shipped in
place and ready to use. To empty: Pull drain hose out of
bottle cap, remove bottle from unit, unscrew cap and dis-
card waste and rinse bottle. Reinstall bottle in unit.
Unscrew
cap
Removable
grate for clean-
ing sump area
Cleaning the drain sump:
On a free standing beverage dispenser remove the
Marvel grate from in front of the tower, clean with soap and
water and dry before reinstalling. Clean the sump area with
On a built in beverage dispenser remove the Marvel
grate and counter top sump, clean with soap and water and
dry before reinstalling. Clean the sump area with soapy
Marvel grate
Counter top
sump
Clean and dry
sump area
Figure 49
Push faucet handle back toward
tower to close the faucet
USING YOUR BEVERAGE DISPENSER AND CARE AND CLEANING
