ITEM NO. PART NO. DESCRIPTION QTY
29 106003 COLLAR 2
30 057012 BOLT M12 x 55-GB5782 2
32 152000 CLUTCH PULLEY ASSY. 1
33 152005 CLUTCH WASHER 1
34 093008 SPRING WASHER 8-GB93 1
35 057008-25 BOLT M8 X 25 - GB5783 1
36 107001 INSIDE BELT COVER 1
37 011544 V-BELT SPA - GB11544 1
38 107000 BELT COVER 1
39 095008 WASHER 8 - GB95 11
40 093008 SPRING WASHER 8-GB93 11
41 057008-16 BOLT M8 X 16 - GB5783 3
42 108100 WHEEL PIN 1
44 061010 NUT M10 - GB6170 1
66 057006 BOLT M6 X 30 4
68 105001 RUBBER CLIP 2
69 061006 NUT M6 4
70 105002 CLIP PLATE 4
90 101100 PROTECTIVE FRAME (OPTIONAL) 1
91 108001 WHEEL SHAFT 1
92 108002 WHEEL 2
93 105003 NUT STRIP 1
94 103001 RUBBER MAT (OPTIONAL) 1
95 103002 FIX STRIP (OPTIONAL) 1
96 057010-40 BOLT M10X40-GB5783 (OPTIONAL) 3
97 093010 SPRING WASHER 10-GB93 (OPTIONAL) 3
98 095010 WASHER10 - GB95 (OPTIONAL) 6
99 A2004001-1 THROTTLE CONTROL LEVER (OPTIONAL) 1
100 1560006-2 THROTTLE CONTROL WIRE (OTIONAL) 1
MS60 PARTS LIST 1
