Specific technical data
2115/2116 2015 2215/2216 2415 2515 3015
Input voltage current frequency
100 - 240 VAC
max.0.35 A
50 - 60 Hz
230 - 240 VAC
max.0.5 A
50 - 60 Hz
100 - 240 VAC
max.0.9 A
50 - 60 Hz
100 - 240 VAC
max. 1.3 A
50 - 60 Hz
10 – 30 VDC
max 4A
10-30 VDC
max 8A
Max. Output Power
16 W 40 W 35 W 67 W 32 W 67 W
Protection at input
Fuse: T1.0 AH 250 V,
5 x 20 mm
Fusible resistor
Fuse: T1.6 AH 250 V,
5 x 20 mm
Fuse: T2.5 AH 250 V,
5 x 20 mm
5 A fuse
on input cable.
10A fuse
on input cable
Protection against ingress of water (IEC 60529)
IP4X
(IP67 availible)
IP3X
IP4X
(IP67 availible)
IP4X
(IP67 availible)
IP4X
(IP67 availible)
IP4X
(IP67 availible)
Insulation Class
Class II Class II Class II Class II
Class III,
common minus
Class III,
common minus
Dimensions (LxWxH)
90x45x32mm (2115)
103,5x46,8x38,7mm
(2116)
100x63x47mm
107x67x36,5mm
(2215)
117x75x44mm (2216)
135x80x44mm 107x67x36,5mm 135x80x44mm
Weight
125g / 150g 220g 250g 350g 250g 350g
Input terminals
- Non-detachable mains cord or 2-pin connector (IEC 60320/C7) for detachable mains cord set (2115, 2215 and 2415 only)
- Exchangeable AC adapters (model 2116 and 2216 only). 2015 has fixed plug-in connector.
- DC/DC chargers 2515 and 3015 has cable in and out.
