MASCOT 2240 - Page 18

18
Input
voltage
Charge LED
indicator
6V 12V 24V 36V 48V
2043
100-240Vac
50-60Hz
Orange CC ch.: Yellow Timer CV ch.: Green Float ch.: Rec. batt. capacity:
10A < 7.35V
7.35V < 10A (4h)
6.85V
50Ah – 500Ah
10A < 14.7V
14.7V < 10A (4h)
13.7V
50Ah – 500Ah
5A < 29.4V
29.4V < 5A (4h)
27.4V
25Ah – 250Ah
3.3A < 44.1V
44.1V < 3.3A (4h)
40.8V
16.5Ah – 165Ah
2.5A < 58.8V
58.8V < 2.5A (4h)
54.8V
12.5Ah - 125Ah
2044 2045
220-240Vac
50-60Hz
Orange CC ch.: Yellow Timer CV ch.: Green Float ch.: Rec. batt. capacity:
20/25A < 7.35V
7.35V < 20A/25A (4h)
6.85V
100Ah – 1000Ah
20A/25A < 14.7V
14.7V < 20A/25A (4h)
13.7V
100Ah – 1000Ah
10A < 29.4V
29.4V < 10A (4h)
27.4V
50Ah – 500Ah
6.7A < 44.1V
44.1V < 6.7A (4h)
41.1V
33.5Ah – 335Ah
5A < 58.8V
58.8V < 5A (4h)
54.8V
25Ah – 250Ah
2640
per
channel
220-240Vac
50-60Hz
Orange CC ch.: Yellow Timer CV ch.: Green Float ch.: Rec. batt. capacity:
10A < 7.35V
7.35V < 10A (4h)
6.85V
50Ah – 500Ah
10A < 14.7V
14.7V < 10A (4h)
13.7V
50Ah – 500Ah
5A < 29.4V
29.4V < 5A (4h)
27.4V
25Ah – 250Ah
3.3A < 44.1V
44.1V < 3.3A (4h)
41.1V
16.5Ah – 165Ah
2.5A < 58.8V
58.8V < 2.5A (4h)
54.8V
12.5Ah - 125Ah
9541
per
channel
220-240Vac
50-60Hz
Orange CC ch.: Yellow Timer CV ch.: Green Float ch.: Rec. batt. capacity:
25A < 7.35V
7.35V < 25A (4h)
6.85V
125Ah – 1250Ah
25A < 14.7V
14.7V < 25A (4h)
13.7V
125Ah – 1250Ah
10A < 29.4V
29.4V < 10A (4h)
27.4V
50Ah – 500Ah
6.7A < 44.1V
44.1V < 6.7A (4h)
41.1V
33.5Ah – 335Ah
5A < 58.8V
58.8V < 5A (4h)
54.8V
25Ah – 250Ah
Charge diagram C
(All standard versions are also available as open frame units)
