MASCOT 2240 - Page 19

19
Input
voltage
Charge LED
indicator
6V 12V 24V 36V 48V
2745
115Vac/
230Vac
50-60Hz
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
20A < 7.35V
7.35V 2.5 – 20A,<4h
6.85V 0 – 20A
100Ah – 1000Ah
20A < 14.7V
14.7V 2.5 – 20A,<4h
13.7V 0 – 20A
100Ah – 1000Ah
10A < 29.4V
29.4V 1.4 – 10A,<4h
27.4V 0 – 10A
50Ah – 500Ah
6.7A < 44.1V
44.1V 1 – 6.7A,<4h
41.1V 0 – 6.7A
33.5Ah – 335Ah
5A <58.8V
58.8V 0.7 – 5A <4h
54.8V 0 – 5A
25Ah – 250Ah
2944 2945
220-240Vac
50-60Hz
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
20A < 7.35V
7.35V 2.5 – 20A,<4h
6.85V 0 – 20A
100Ah – 1000Ah
20/25A < 14.7V
14.7V 2.5 – 20A,<4h
13.7V 0 – 20A
100Ah – 1000Ah
10A < 29.4V
29.4V 1.4 – 10A,<4h
27.4V 0 – 10A
50Ah – 500Ah
6.7A < 44.1V
44.1V 1 – 6.7A,<4h
41.1V 0 – 6.7A
33.5Ah – 335Ah
5A < 58.8V
58.8V 0.7 – 5A <4h
54.8V 0 – 5A
25Ah – 250Ah
2841
per
channel
220-240Vac
50-60Hz
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
5A < 7.35V
7.35V 1.5 – 5A,<4h
6.85V 0 – 5A
25Ah – 250Ah
5A < 14.7V
14.7V 1.5 – 5A,<4h
13.7V 0 – 5A
25Ah – 250Ah
2.5A < 29.4V
29.4V 0.6 – 2.5A,<4h
27.6V 0 – 2.5A
12.5Ah – 125Ah
1.7A < 44.1V
44.1V 0.4 – 1.7A,<4h
41.1V 0 – 1.6A
8.5Ah – 85Ah
1.2A <58.8V
58.8V 0.3 – 1.2A <4h
54.8V 0 – 1.2A
6Ah – 60Ah
2245
220-240Vac
(115Vac)
50-60Hz
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
40A < 7.35V
7.35V 5 – 40A,<4h
6.85V 0 – 40A
200Ah – 2000Ah
40A < 14.7V
14.7V 5 – 40A,<4h
13.7V 0-40A
200Ah - 2000Ah
20A < 29.4V
29.4V 2.5 – 20A,<4h
27.4V 0-20A
100Ah – 1000Ah
N.A. N.A.
2440(P)
2440B(P)
100-240Vac
50-60Hz
max.1.6A
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
4.5A < 7.35V
7.35V 1.2 – 4.5A<4h
6.85V 0 – 4.5A
22.5Ah – 225Ah
4A < 14.7V
14.7V 1.2 –4A,<4h
13.7V 0 – 4A
20Ah – 200Ah
2.5A < 29.4V
29.4V 0.6 – 2.5A,<4h
27.6V 0 – 2.5A
12.5Ah – 125Ah
1.6A < 44.1V
44.1V 0.4 – 1.6A,<4h
41.1V 0 – 1.6A
8Ah – 80Ah
1.2A < 58.8V
58.8V 0.3 – 1.2A <4h
54.8V 0 – 1.2A
6Ah – 60Ah
Charge diagram D
(P) = 2MOPP version. (All standard versions are also available as open frame units).
