MASCOT 2240 - Page 20

20
Input
voltage
Charge LED
indicator
6V 12V 18V 24V 36V 48V
3743
100Vac/
240Vac
50-60Hz
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
1.5A < 7.35V
7.35V 0.4-1.5A<4h
6.85V 0-1.5A
7.5Ah-75Ah
1A<14.7V
14.7V 0.25-1A<4h
13.7V 0-1A
5Ah-50Ah
0.56A<29.4V
29.4V 0.15-0.56A<4h
27.4V 0-0.56A
2.8Ah-28Ah
0.4A<44.1V
44.1V 0.1-0.4A<4h
41.1V 0-0.4A
2Ah-20Ah
0.3A<58.8V
58.8V 0.1-0.3A<4h
54.8V 0-0.3A
1.5Ah-15Ah
3546
100Vac/
240Vac
50-60Hz
Yellow CC ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
2.7A < 7.35V
7.35V 0.5-2.7A<4h
6.85V 0-2.7A
13.5Ah-135Ah
2A < 14.7V
14.7V 0.5-2A<4h
13.7V 0-2A
10Ah- 100Ah
1A<29.4V
29.4V 0.25-1A<4h
27.4V 0-1A
5Ah-50Ah
0.65A<44.1V
44.1V 0.15-0.65A<4h
41.1V 0-0.65A
3.25Ah-32.5Ah
0.5A<58.8V
58.8V 0.12-0.5A<4h
54.8V 0-0.5A
2.5Ah-25Ah
*
3540(P)
3540B(P)
220-240Vac
50Hz
Max. 2.4A
Yellow CC ch.: Yellow CV ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
20A < 7.35V
7.35V>15.5A
7.35V <15.5A<4h
6.85V 0-18A
100Ah – 1000Ah
20A < 14.7V
14.7V>14.5A
14.7V <14.5A<4h
13.7V 0 – 18A
100Ah – 1000Ah
13.2A < 22.05V
22.05 V>10.5 A
22.05 V <9.0A<4h
20.55V 0 – 11A
66Ah – 660Ah
10A < 29.4V
29.4V>8.0A
29.4V <8.0A<4h
27.4V 0 – 8.5A
50Ah – 500Ah
6.6A < 44.1V
44.1V>5.5A
44.1V <5.5A<4h
41.1V 0-5.7A
33Ah – 330Ah
5A < 58.8V
58.8V>3.5A
58.8V <3.5A<4h
54.8V 0-4.3A
25Ah – 250Ah
*
3540(P)
3540B(P)
115Vac
50-60Hz
Max 4.3A
Yellow CC ch.: Yellow CV ch.: Flash Yellow CV ch.: Green Float ch.: Rec. batt. capacity:
20A < 7.35V
7.35V>14.5A
7.35V <14.5A<4h
6.85V 0-15A
100Ah – 1000Ah
17A < 14.7V
14.7V>14.5A
14.7V <14.5A<4h
13.7V 0 – 15A
85Ah – 850Ah
11.3A < 22.05V
22.05V>9.0A
22.05V <9.0A<4h
22.55V 0 – 9.5A
56.5Ah – 565Ah
8.5A < 29.4V
29.4V>7.0A
29.4V <7.0A<4h
27.4V 0 – 7.5A
42.5Ah – 425Ah
5.7A < 44.1V
44.1V>4.5A
44.1V <4.5A<4h
41.1V 0-4.7A
28.5Ah – 285Ah
4.3A < 58.8V
58.8V>3.5A
58.8V <3.5A<4h
54.8V 0-3.6A
21.5Ah – 230Ah
Charge diagram E
(P) = 2MOPP version (B) =Special open frame PCB (All standard versions are also available as open frame units) *
Output automatically derated when operated at high amb. temperature.
The max. battery capacities given in the tables above are for guidance only. For import to the U.S.A.: see the U.S. DOE Compliance Certification Database for maximum battery capacity allowed.
