Model: PM-2160-A
Doc. Ref. no. : m20Aom201
Issue no. 02
User’s Manual Page 8 of 36
Real time clock & date
ON hour ,LOAD hour ( up to 65000 hours Recording)
Power Interruption count (up to 65000) with (Last Power OFF & Latest Power ON)Time & Date
Environmental
Working temperature
0 to 55º C
Storage temperature
-10 to 70ºC
Relative humidity
30-95% non-condensing
Warm up time
5 minutes
Accuracy Table
Class 0.2
Optional
Class 0.5
Optional
Class 1.0
(Standard)
Voltage
0.25% of reading
Current
0.1% of reading
0.2% of reading
0.5% of reading
Frequency
±0.01Hz
Power Factor
0.2% of FS
0.25% of FS
0.5% of FS
Active Power* (≥0.02
of Ib)
0.2% of reading +/-
0.01% of FS
0.3% of reading +/- 0.01%
of FS
1.0 % of reading + 0.01%
of FS
Reactive Power*
(≥0.02 of Ib)
0.2% of reading +/-
0.02% of FS
0.5% of reading +/- 0.02%
of FS
1.0 % of reading + 0.02%
of FS
Apparent Power*
(≥0.02 of Ib)
0.2% of reading +/-
0.02% of FS
0.5% of reading +/- 0.02%
of FS
1.0 % of reading + 0.02%
of FS
Active Energy*
Class 0.2s as per
IS14697/ IEC 62053-22
Class 0.5s as per
IS14697/ IEC 62053-22
Class 1.0 as per
IS13779/IEC 62053-21
Reactive Energy*
Class 0.2s as per
IS14697
Class 0.5s as per IS14697
Class 1.0 as per IS13779
Apparent Energy*
Class 0.2s
Class 0.5s
Class 1.0
(*PF 0.5 Lag-1.0 - 0.8 Lead Applicable for Power & Energy Parameter)
Output
Communication Output
Interface
RS485
Baud rate
9600, 19200, 38400 (Selectable)
Start bit
1
Stop bit
1
Protocol
Modbus-RTU
Pulse output
Type
WH/VARH/VAH
AC/DC Ratings
200VAC / 300VDC,100mA AC/150mA DC
Pulse rate
Programmable from 100 to 60000 pulses per KWh[I]/KWh[E]/KVARh[I]
/KVARh[E] /KVAh/ MWh[I]/MWh[E]/MVARh[I] /MVARh[E] /MVAhof total.
Pulse Duration
40 mSec ± 10%
Output Type
Open collector [External Excitation Required]
Auxiliary Power Supply
Power Supply
85-265VAC, 50/60Hz or 100-300VDC
Burden
Less than 4VA [LED]
Less than 3VA [LCD Panel with Backlight],
Less than 2VA [LCD Panel w/o Backlight through Configuration]
Energy Update Rate
500 mSec
