Massive Audio M6 - Massive Audio MC 10 Speaker Specifications; MC 10 Thiele & Small Parameters

Specifications MC 10
Nominal Basket Diameter 10.2",260mm
Nominal Impedance 8 ohms
RMS Watts 400 W
Music Program 800 W
Resonance 60 Hz
Usable Frequency Range 60Hz-4KHz
Sensitivity 99.2 dB
Magnet Weight 77.5 oz
Gap Height 0.4",10mm
Voice Coil Diameter 3", 75.5MM
Resonant Frequency (fs) 60 Hz
DC Resistance (Re) 5.6
Mechanical Q (Qms) 6.6
Electromagnetic Q (Qes) 0.25
Total Q (Qts) 0.24
Mechanical Compliance of Suspension (Cms) 292.4 uM/N
BL Product (BL) 15.8 TM
Diaphragm Mass Inc. Airload (MMs) 29.1 g
Surface Area of Cone (Sd) 0.0346 sqm
Overall Diameter 10.2",260mm
Baffle Hole Diameter 8.86",225mm
Front Sealing Gasket Fitted as standard
Rear Sealing Gasket Fitted as standard
Mounting Holes Diameter 0.27",7mm
Mounting Holes B.C.D. 9.6",244mm
Depth 4.13",105mm
Net Weight 15.75Lbs
Magnet Composition Ferrite magnet
Core Details Vented and extended core
Basket Materials Cast aluminum basket
Cone Composition Paper Cone
Cone Edge Composition Cloth cone edge
Dust Cap Composition Solid composition paper dust cap
Materials of Construction
Thiele & Small Parameters
Mounting Information
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
