Massive Audio M6 - Massive Audio MC 12 Speaker Specifications; MC 12 Thiele & Small Parameters

Specifications MC 12
Nominal Basket Diameter 12.1",308mm
Nominal Impedance 8 ohms
RMS Watts 400 W
Music Program 800 W
Resonance 44 Hz
Usable Frequency Range 44Hz-4KHz
Sensitivity 99.4 dB
Magnet Weight 77.5 oz
Gap Height 0.4",10mm
Voice Coil Diameter 3", 75.5MM
Resonant Frequency (fs) 44 Hz
DC Resistance (Re) 5.6
Mechanical Q (Qms) 7.89
Electromagnetic Q (Qes) 0.24
Total Q (Qts) 0.23
Compliance Equivalent Volume (Vas) 105.15 L
Mechanical Compliance of Suspension (Cms) 313.25 uM/N
BL Product (BL) 17.3 TM
Diaphragm Mass Inc. Airload (MMs) 45.83 g
Surface Area of Cone (Sd) 0.0511 sqm
Overall Diameter 12.1",308mm
Baffle Hole Diameter 10.94",278mm
Front Sealing Gasket Fitted as standard
Rear Sealing Gasket Fitted as standard
Mounting Holes Diameter 0.22",5.5mm
Mounting Holes B.C.D. 11.61",295mm
Depth 4.45",113mm
Net Weight 15.95Lbs
Coil Former Kapton former
Magnet Composition Ferrite magnet
Core Details Vented and extended core
Basket Materials Cast aluminum basket
Cone Composition Paper Cone
Cone Edge Composition Cloth cone edge
Dust Cap Composition Solid composition paper dust cap
Materials of Construction
Thiele & Small Parameters
Mounting Information
MASSIVE AUDIO PRO AUDIO SPECIFICATIONS
