Table of conguration variables
CV Description D A Range Note:
118 A5: Special Function 0 √ see Attachment 5 + 6
119 A6: Command Allocation 6 0... 16 see Attachment 3
120 A6: Special Function 0 see Attachment 7
121 A3: RC Servo Conguration 0 see Attachment 8
122 A3: RC servo, lower end position 16 5... 50 depending on RC servo
123 A3: RC servo, upper end position 32 5... 50 depending on RC servo
127 A3: RC servo, time base 1 1... 15 1 = fast / 1 unit = 10 ms
128 Shuttle-Contact 1 0 0 ... 250 0 = deactivated,
4..250 = 2..125 Sek. Sperrzeit
255 Decoder type --- --- read only
Attachment 1: CV 29 - NMRA conguration table
Bit Value OFF (Value=0) ON Note
0 1 Standard driving direction Reverse driving direction
1 2 14 Speed Steps 28 Speed Steps automatic recognition
of 128 speed steps
2 4 Digital operation only Digital and analog operation
4 16 Internal speed curve Programmable speed curve CV67 - 94
5 32 Short address
(stored in CV1)
Long address
(stored in CV17 and 18)
Attachment 1 : Basic values of CV29
Value Function
0 14 speed steps + analog operation blocked
2 28 speed steps + analog operation blocked
4 14 speed steps
6 28 speed steps
34 long address + 28 speed steps + analog operation blocked
38 long address + 28 speed steps
