Massoth eMOTION M - Page 33

33
Attachment 2: CV 49 - MASSOTH conguration table
Bit Value OFF (Value=0) ON Note
0 1 Parallel data transfer only Serial + parallel data transfer automatic detection
of seriell/parallel
1 2 Digital load control = OFF Digital load control = ON
2 4 Analog load control = OFF Analog load control = ON
3 8 A1-Output standard function Fast pulse string (P-Update)
on A1
Bit 3 „on“ only with
bit 0 = „on“
4 16 Massoth bus SUSI bus
Attachment 3: CV 51, 52, 54, 56, 113, 115, 117, 119 - Switch. output commands
Value Application Note
0 - 16 0 = Switch function with light key,
1 ... 16 = Switch function with F-key No. 1-16
+ 64 Switching Output „on“ in Reverse Only additional value must be added
+ 128 Switching Output „on“ in Forward Only additional value must be added
Attachment 4: CV 53, 112 - Dimming values
Value Application Note
1 - 32 Voltage in percent of track voltage on output 1 unit = approx. 3% of track
voltage (0,75V)
1 = 3% of track voltage (0,75V)
32 = 100% track voltage (24V)
+ 64 A1 resp. A3 is dimmed only A1 = value in CV53
A3 = value in CV112
additional value must be added
+ 128 A2 resp. A4 is dimmed only A2 = value in CV53
A4 = value in CV112
additional value must be added
+ 192 Both outputs will be dimmed additional value must be added
