Attachment 5: CV 55, 57, 114, 116, 118 - Special functions A1 - A5
Value Application Note
0 0 = Steady „on“
(Standard operation)
1 - 15 Flashing symmetrical
(Time base 0,25 sec/value)
symmetric ashing
+ 64 Short term function (Monoop)
(Time base 0,25 sec/value)
output switches off after time
out
additional value must be added
+ 128 Asymmetric ashing (1/3 on, 2/3 off) short „on“, long „off“
additional value must be added
+ 192 Asymmetric ashing (2/3 on, 1/3 off) short „off“, long „on“
additional value must be added
Attachment 6: CV 57, 116, 118 – Expanded special functions A2 + A4
Value Application Note
16 Inverse coupling with output A1, rsp. A3
Alternate ashing
CV57 (A2 with A1)
CV116 (A4 with A3)
31 Charging control of voltage buffer in programming mode
(only A5)
Only in CV118
Buffer controlled by A5
Attachment 7: CV120 – Special function A6
Value Application Note
0 0 = continuous operation (regular switch function)
1 - 15 1 … 15 = time base for the sound pulse trigger (chuffs) 1 = slow pulse
15 = fast pulse
Attachment 8: CV121 - RC Servo function
Value Application Note
0 0 = RC-servo deactivated
1 1 = RC-servo activated
+ 4 control level inverted
+ 8 switch-off after movement
