4. Installation
Always install the i-Size seat on the vehicle seat, even if not in use.
This i-Size seat is suitable for children with a height of 40-150cm
40-105cm(rearward) 76-105cm(forward) 100-150cm(forward) 100-150cm(forward)
4.1
40-105cm rear facing, 76-105cm forward facing ISOFIX
+ support leg + 5-point harness
Opening the support leg
Turn the supporting leg 90° from the
base and pull it outward. When you hear
the „click“ sound, it indicates that the
head release of the supporting leg A is in
the correct position.
(The seat can be instaled and used in
reverse).
NOTICE! When the support leg is pulled
into the correct position, the whole green
bar can be seen in front
ISOFIX + support
leg + 5 point harness
ISOFIX + support
leg + 5 point harness
ISOFIX +
vehicle belt
Vehicle belt
A
