Joker Series (Passive). Version 1.4 Jan14 8
3.3. Full range cabinet with subwoofer
The JK12W, JK15W, JK18W1 and JK18W2 are equipped with a M20 Plate for a
35mm distance rod. You can use it to place over the subwoofer the models that are
equipped with the tripod socket (JK26, JK10, JK12 and JK15). Be careful not to use
this system on non-flat surfaces as it may become unstable.
Fig.9. Full range cabinet with subwoofer
3.4. Live applications (mobile)
For a mobile application, whether it is an outdoor or indoor installation, the common
location is to place the bass units (one or two per channel) on each side of the stage.
Fig.10. Mobile applications
To obtain a clear and free-distortion reproduction, it is advisable to place the mid-high
units on top of the low units keeping between them an approximate height of two
meters. If such height cannot be achieved nor maintained, it is advisable to use the
classical tripod for each mid-high cabinet and leave the low units on the floor.
