Master Audio
Joker Series (Passive). Version 1.4 Jan14 7
3. MOUNTING AND PLACEMENT
For a proper installation of the acoustic cabinet systems, it is strongly recommended
to read carefully the following advices.
3.1. Placement
The Full Range cabinets should be located in a high position (between two or three
meters), slightly inclined to the audience. If the loudspeakers are located too low, the
listeners at the end of the room will not hear a good sound quality.
.
Fig.7. Flying placement
It is advisable to locate the subwoofer units on the floor as they can take advantage
of the so-called “floor-effect”, thus increasing the response in the low frequencies.
If possible, place the subwoofers under the same acoustic axis used for the satellites.
If the above option cannot be carried out, then they should be placed in an
intermediate point between the left and right channels.
3.2. Tripod use
The JK26, JK10, JK12 and JK15 models are equipped with a tripod socket for use
with a standard 35mm tripod.
Do not use the tripod on non-flat floors and be careful not to raise the cabinet too high
on the tripod, as it may become unstable.
Fig.8. Full range cabinet with tripod
