Master audio P-26A - Page 47

Master Audio
PRO Series.Version 1.5 Nov10
47
1 2 5 3 4 1
Fig.23.
UN-10 bracket
4. TECHNICAL FEATURES
4.1. P26 technical features
Line input 1.5V/10k

Mains 230V +/-10%
Full power consumption 2A
Maximum SPL 118dB
Frequency response (-10 dB) 65Hz-20kHz
Nominal directivity (-6dB) 90º conical
Components
LF 2x6" woofer
HF 1x neodymium tweeter
Enclosure
Height 500mm
Width 239 mm
Depth 258 mm
Net weight 8.4Kg
Connections 2 x XLR (IN/LINK), 2 x AC (IN/LINK)
Material Birch plywood, Steel front grille
Finish Black
4.2. P10A technical features
Line input 1.5V/10k

Mains 230V +/-10%
Full power consumption 2A
