- Disconnect all the connected peripheral equipments (sources, pre-amplifiers,
and loudspeakers). Leave the amplifier “alone” and verify if the anomaly
disappears or if it remains in only one channel or both.
- Temperature: Cooling (possible air obstruction. Check if the fans work and
make an internal cleaning).
- Short circuit: Check the state of the loudspeaker line (possible short circuit,
disconnect and check if the anomaly disappears).
- DC at the output: Possible serious breakdown. Contact an authorized
technical service.
In all cases it is recommended to go through all previous checkpoints before
contacting the authorized technical service and reporting the observed problem.
12 - TECHNICAL FEATURES
Technical Features: SM-1000 SM-2000 SM-3000 SM-4000
Voltage Gain:
Input Sensitivity:
Input Impedance:
Slew Rate
Output Power:
Stereo 8 ohm
1
310W x2 650W x2 850W x2 1200W x2
(1kHz - 0,1% THD)
2
Stereo 4 ohm
500W x2 1050W x2 1400W x2 2000W x2
Stereo 2 ohm
1
600W x2 1350W x2 2300W x2 3000W x2
Bridge 8 ohm
1000 W 2200 W 3000 W 4100W
Bridge 4 ohm
1200 W 2900 W 4600 W 6200W
Average current draw:
(1/3 power)
2
3 A 5 A 6 A 8 A
Damping Factor:
(1 kHz@8 ohm)
> 200 > 300 > 300 > 300
Crosstalk: -60 dB -60 dB -65 dB -65 dB
S / N Ratio
(A weighted)
102 dB (A) -104 dB (A) -105 dB (A) 108 dB (A)
Dimensions (H x W x D)
Net Weight: 9 Kgs. 12 Kgs. 14,9 Kgs. 15,5 Kgs.
20 Hz - 20k Hz (0/-0,5 dB)
Note (1): Driving the amplifier at 2 ohms channel / 4 ohms bridge mode in poor ventilation
conditions may cause a thermal overload protection. 2 ohms power is time limited by switch mode
power supply overload.
Note (2): Continuous burst tone 20 ms (0dB) / 480 ms (-20dB) in accordance with EIA RS-490 and
IEC 60268-3 / IHF A-202)
Specifications subjected to change without prior notice (nov 2009)
If you follow the instruction manual and recommendations, we are sure that this
amplifier will always perform within the predetermined parameters, ensuring its long
life and total efficiency.
