Master Audio
Xcellence Line Array Series 208.Ver 1.2 Sep 12
38
Fig.33. X-215W Flying, three units in cardioid configuration
8.4. X-208 + X-215W Flying
It is useful to fly low frequency reinforcement units on the top of the system, as they
are the heaviest enclosures. Place the subwoofers as has been explained in section
8.3. Join the last unit of X-215W onto the first unit of X-208 through the FA-X208/215
accessory (see FA-X208/215 specific manual).
Please select “SW” position on X-208 back guide for the upper cabinet
Follow section 8.2 to fly the rest of X-208 units (choose between a flat line array or a
curved line array). We recommend 1-2 units of X-215W for each 4 units of X-208.
FA-X208/215
Fig.34. X-208 + X-215W flying with FA-X208/215 accessory
