MASTER KITCHEN MKRF 320I NF E - Page 33

6) Remove the the upper hinge of freezer door and plug pin.
7) Remove the freezer door, the bottom hinge and the hole caps.
4) Exchange the R:bottom hinge and R:upper hinge , then install them according to below steps,
and install the top hole caps.
5) of refrigerator door them for 180°，
refrigerator door
Remove the two fixed blocks and rotate
and install them on other side of .
F:upper hinge
F:bottom hinge
hole caps
R:bottom hinge
hole caps
fixed block
R:upper hinge
180°
Step 1:
install lef t bottom hinge
Step2:
put refrigerator
door on left botto m
hinge vertically
Step 3:
install lef t upper hinge
EN-11
