Save This Manual
You will need this manual for future reference. It is recommended that you keep your invoice for this winch inside the front
cover of this manual and keep both in a safe, clean and dry place for future reference.
Replacement parts and accessories are not available for your winch. Should this product not function or be missing any
parts, do not use it and return it to place of purchase. Always have a qualified technician perform all repairs on your winch,
never attempt to repair your winch yourself.
INTRODUCTION ......................................1
SAVE THIS MANUAL...................................1
PERFORMANCE SPECIFICATIONS .........................1
INCLUDED ACCESSORIES ...............................2
PRODUCT FEATURES ..................................2
PULLING CAPACITY ...................................2
GENERAL SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . 3
MOUNTING INSTRUCTIONS..............................4
WIRING INSTRUCTIONS ................................4
OPERATING INSTRUCTIONS .............................5
USING THE HAND CRANK...............................8
MAINTENANCE INSTRUCTIONS...........................8
Warranty ...........................................9
Table of Contents
Thank you for purchasing a Master Lock
®
electric winch. We hope you
will be pleased with the performance and reliability of your winch. Your
winch was designed for non-industrial use. All other applications may
void warranty.
As with any power tool, there is a potential for personal injury if your
winch is improperly installed or operated. To ensure safe operation
of your winch, it is extremely important that you read and understand
this Owner’s Manual prior to installing and operating this winch.
Make sure that anyone else who operates your winch also reads and
understands this manual.
Introduction
Capacity: 6,000lbs Rolling, 5,000lbs Marine, 2,000lbs Pulling
Capacity,
Max Boat Weight: 5,000lbs
Duty Cycle:
Fully Loaded @ 2,000lbs, 6 to 8 minutes operation.
Allow 5 minutes to cool before resuming use.
Light Load @ 150lbs, 6 to 8 minutes operation.
Allow 1 minute to cool before resuming use.
Cable Length: 30ft (29ft working length)
Power Cable: 20’
Mounting Plate: 8-3/4” x 4-15/16” x 5/32”
Net Weight: 27lbs
Max Boat Size: 18ft
Line Speed: 6 Feet/Minute with Load
Power Supply: 12 Volts
Stall Load: 2,100lbs
Current Draw:
@150lbs: 4 to 6 amps
@2,000lbs: 20 amps
Remote Control Cord: 9’9” long
Overall Dimensions: 9-1/2” x 7-1/2” x 10”
Performance Specifications
1
Pull Strength Performance Ratings
Cable Layer Capacity in lbs Capacity in kg
1 2,000 907
2 1,510 685
3 1,210 549
4 1,010 458
