The DIALOG® 3G endpoint (DTMW) is an RF transceiver used
to communicate metered consumption data in Automatic Meter
Reading (AMR) systems.
3G features an exclusive design that completely encapsulates
the encoder electronics, transceiver, antenna, and batteries
under the register glass. A design called ConnectionFree™.
CAUTION: The User and the Installer should be aware that changes and modifications to the equipment
not expressly approved by Master Meter could void warranty and the user's authority to operate the
equipment.
Professionally trained personnel should install the equipment.
The antenna used for this transmitter must be installed to normally provide minimum separation distance
of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other
antenna or transmitter
ATTENTION! This type of note is used to warn of potential physical harm to the user or hardware. It is
critical that you pay strict attention to WARNING notes, read the information carefully, and heed the
advice/instructions.
Chapter 1.
Getting Started
Chapter 2.
Installing the
Provides an overview of the DTMW
endpoint installation, including installation
options, siting, and required tools.
Provides step-by-step instructions for wiring
the endpoint to a register and installing the
endpoint using the rod mount, on a wall or
similar surface, or on a pipe.
