OWNER’S MANUAL
Submersible
Sump Pumps
Installation/Operation/Parts
For further operating,
installation, or maintenance assistance:
Call 800-628-9439
©2012 TRU526 (09/27/12)
1569 0195 VERT GEN
1572 0195 Vert GEN
Chicago, IL 60631
Phone: 800-628-9439
www.masterplumberpump.com
539906
539914
540015
540037
540045

Questions and Answers

  • D
    derekallenAug 6, 2025
    What to do if my Master Plumber Water Pump won’t start?
    • C
      Claire AustinAug 6, 2025
      If your Master Plumber Water Pump isn't starting, first ensure it's properly plugged into a working outlet. Check the fuse and replace it with the correct size if it's blown. Also, verify the line voltage; if it's too low, inspect the wiring from the main switch. If the voltage is OK, contact your power company or hydro authority. If none of these steps work, the motor or float switch might be defective, requiring replacement. Lastly, check for any obstructions in the impeller float; if it won’t turn, remove the lower pump body to clear any blockages.
  • K
    Kathleen PattersonAug 14, 2025
    Why is my Master Plumber 539906 running but not pumping water?
    • S
      Shawn MortonAug 14, 2025
      If your Master Plumber Water Pump is running but not delivering enough water, start by checking if the pump is correctly plugged into a proper outlet to ensure adequate line voltage. Next, examine the impeller for any obstructions and clean them out. If the impeller is plugged or the parts are worn, clean the impeller or replace the pump. If you have a check valve, ensure it has a vent hole drilled between 1/16” and 1/8” in diameter, positioned between the pump discharge and the check valve, about 1-2” above where the discharge pipe screws into the pump discharge and below the waterline. Also, inspect the intake screen for any restrictions and clean it. Finally, make sure the check valve is installed correctly.
  • H
    Heather MilesAug 21, 2025
    What to do if my Master Plumber Water Pump won't shut off?
    • M
      mconnerAug 21, 2025
      If your Master Plumber Water Pump won't shut off, the float switch may be defective and needs replacement. Also, check for any restrictions in the discharge, such as obstacles or ice in the piping; if present, remove the pump and clean both the pump and the piping. Additionally, inspect the float for obstructions and remove them. Lastly, check the intake screen for restrictions; remove the pump and clean both the intake screen and the impeller.
  • W
    Wendy ChoiAug 29, 2025
    Why does my Master Plumber 539906 Water Pump start and stop too often?
    • C
      Christopher BlairAug 29, 2025
      If your Master Plumber Water Pump starts and stops too frequently, it could be due to backflow of water from the piping. In this case, install or replace the check-valve. Another possible cause is a faulty float switch, which would require replacement.

Summary

Safety

Important Safety Instructions

Comprehensive safety guidelines for pump usage and maintenance.

California Proposition 65 Warning

Warning regarding chemicals linked to cancer and reproductive harm.

Installation

Performance Data

GPH performance charts for various pump models and head heights.

Specifications

Technical details including power, temperature, discharge, and electrical requirements.

Float Switch Installation

Instructions for installing vertical float switches on sump pumps.

Operation

Vertical Switch Assembly

Step-by-step guide for assembling the pump's vertical float switch.

Repair Parts

Plastic Series Parts

Part identification for plastic sump pump models.

Cast Iron Series Parts

Part identification for cast iron sump pump models.

Troubleshooting

Warranty Information

Limited Warranty Terms

Details warranty period, eligibility, and claims process for Master Plumber products.

Sewage Pump Handling

Specific instructions for sewage pumps, including contamination hazards and returns.

Warranty Exclusions

Lists products with different warranty periods and general warranty limitations.

General Warranty Conditions

Outlines general terms, conditions, and liability limitations for the warranty.

Master Plumber 539906 Specifications

General IconGeneral
Model539906
BrandMaster Plumber
Voltage115 V
Horse Power0.5 HP
Maximum Discharge Flow50 GPM
