EN
TECHNICAL DATA
MODEL AC 1400 E AC 1600 E
Cooling capacity
14000 BTU/hr
4102watts
16000 BTU/hr
4688watts
Power/Ampere consumption for cooling 1655 W/ 7.5A 1875 W/ 8.5A
Air volume (max. speed) 550m
3
/h 600m
3
/h
Humidity removal capacity 1.6L/hour 2.0L/hour
Power supply 220-240V~. 50Hz
Compressor Rotary
Refrigerant R410A
Fan speed 3
Timer 124 hours
Working temperature Cooling: 18 ~ 32
o
C
Exhaust pipe Ø 142x1500mm
Net Weight 33 kgs 37 kgs
Dimension 422x443x825 mm (WxDxH)
Remark:
1. Measuring conditio for above is as per EN 14511:
Cooling: DB=35°C, WB=24°C
*DB – temperature of dry bulb = room temperature, WB* - temperature of web bulb = relative humidity
2. Test condition for data in our rating label is as per safety regulation: EN 60335-2-40
3. Current & Fuse: F2L250V or T2L250V
BEFORE USE
GENERAL SAFETY
ONLY USE IN THE UPRIGHT POSITION ON A
FLAT LEVEL SURFACE AND AT LEAST 50cm
FROM ANY OBJECTS (Fig 1 & 4).
DO NOT PLACE OBJECTS ON THE UNIT OR
RESTRICT AIR INLET / OUTLET (FIG. 2).
CLOSELY SUPERVISE ANY CHILDREN AND
PETS WHEN UNIT IS IN USE.
THIS APPLIANCE IS NOT INTENDED FOR USE BY
PERSONS (INCLUDING CHILDREN) WITH
REDUCED PHYSICAL, SENSORY OR MENTAL
CAPABILITIES, OR LACK OF EXPERIENCE AND
KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN
SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON
RESPONSIBLE FOR THEIR SAFETY. CHILDREN
SHOULD BE SUPERVISED TO ENSURE THAT THEY
DO NOT PLAY WITH APPLIANCE.
ELECTRICAL SAFETY
FOR INDOOR USE ONLY.
SWITCH OFF AND UNPLUG WHEN NOT IN USE.
DO NOT USE IN HUMID OR WET
ENVIRONMENTS (FIG 3)
DO NOT PULL THE UNIT ALONG BY THE CORD.
IF THE SUPPLY CORD IS DAMAGED, IT MUST
BE REPLACED BY AN ELECTRICIAN OR
SIMILARLY QUALIFIED PERSON, TO AVOID
HAZARD.
FOR MAXIMUM EFFICENCY
CLOSE DOORS AND WINDOWS
KEEP CURTAINS OF BLINDS CLOSED DURING
THE SUNNIEST PART OF THE DAY
KEEP FILTERS CLEAN
ONCE ROOM HAS REACHED THE DESIRED
CONDITIONS, REDUCE TEMPERATURE AND
VENTILATION SETTING
PARTS
Front (Fig. 5)
1. Control Panel
2. Air vent
3. Hanle
4. Caster
Back (Fig. 6)
5. Air filter
6. Air inlet
7. Cord storage
8. Outlet of exhaust air
9. Water stopper / outlet of condensed water
Accessories (Fig. 7)
10. Exhaust hose.
11. PVC strip - for filling the open window space
12. PVC strip - for filling the open window space
13. PVC strip (with hole) - for filling the open window space
and with hole for connection to tie-in
14. Outward adaptor - for insertion over hose and into PVC
strip (or into hole in the wall/window).
15. Cover for outward adaptor
16. Remote control.
17. Active carbon filter
18. Tube for continuous drainage
