OWNER’S MANUAL
ILLUSTRATED
PARTS LIST
For Model MGH10000A
Fuel Tank and Roll Cage
This list contains replaceable parts used in
your generator. When ordering parts, fol-
low the instructions listed under Replace-
ment Parts on page 32 of this manual.
KEY PART
NO.
NUMBER
DESCRIPTION QTY.
1 079503-25AA Gas Tank Assembly 1
2 105905-01 Roll Cage 1
3 105906-01 Axle Mount 1
4 102933-03 Axle 1
5 102932-01 Wheels 2
6 WP-16C Flat Washer, 1" 4
7 C4-12C Cotter Pin 2
8 100135-01 U-Bolt 2
9 NEC-5C Lock Nut, 5/16-18 22
10 WP-5C Flat Washer, 5/16" 30
11 103880-01 Lock Nut,1/4-20 4
12 WP-4C Flat Washer, 1/4" 8
13 097190-06 Gas Cap w/Fuel Gage 1
14 M51151-02 Fuel Line 1
15 M10990-3 Bushing 1
16 106988-01 Barbed Connector, 1/4" 1
17 25985008 Fuel Line 1
18 105035-01 Handle 2
19 103046-01 Grip 2
20 103057-01 Plug 2
21 H8C5-20C Bolt, 5/16-18 x 2.5" 4
22 099750-01 Bolt, J-Hook 5/16-18 2
23 099749-01 Battery Bracket 1
24 105908-01 Battery Mount 1
25 17529000 Shock Mount 3
26 102962-02 Spreader 1
27 H5C4-24C Bolt, 1/4-20 x 3" 4
28 26302006 Bolt, 1/2-10 x 1" 2
29 WLI-8 Internal Tooth Lockwasher 2
30 14138000 Ground Strap 1
31 M10908-74 Tapping Screw, 1/4-20 x .5" 1
32 WLE-5 External Tooth Lockwasher 1
33 106775-02 Side Panel 1
34 106775-01 Side Panel 1
35 106776-01 Top Cover 1
36 100410-01 Sems Screw, 8-18 8
37 HC5-14C Bolt, 5/16-18 x 1.75" 6
PARTS AVAILABLE - NOT SHOWN
099866-05 Safety Information Decal 1
100003-04 Operation Decal 1
099873-01 Battery Cable (Positive, Red) 1
099873-05 Battery Cable (Negative, Black) 1
HC4-6C Screw, 1/4-20 x .75" 2
105951-01 Muffler 1
106108-01 Muffler Hanger 1
