([SORGHG9LHZ
Figure 4: Exploded View of MAC-20F-DDF-B
1(9(5/($9($)$1
81$77(1'(':+,/(
23(5$7,1*25:+,/(
&211(&7('72$32:(5
6285&(
,WHP 'HVFULSWLRQ 3DUW1XPEHU
1 Front Guard 95-032-2000
2 Fan Blade Assembly 95-003-2000
3 Rear Guard 95-032-2001
4 Power Switch 95-031-2000
5 Motor 95-030-2000
6 Adjustment Knob 95-015-2000
7 Fan Frame 95-009-2000
8 Plastic Spacer 95-015-2000
9 Adjustment Bolt 95-015-2001
N/A Power Cord 95-026-2000
