MASTER

Water Conditioning Corp.

MWC-SERIES GROUNDING INSTRUCTIONS

IMPORTANT

All MWC-Series UV systems must be properly grounded. The vessel must be grounded

to the MWC-Power Supply to make a complete ground.

MWC-SERIES

Grounding Lug Installation

Grounding Lug

Front View of Bracket

Insert stripped green ground wire into ground lug

and hand tighten with screw driver.

Top View of Bracket

14 gauge green ground wire

from power supply
