Master POWER-STEPPER User Manual

6
EN
Assemble instructions
Step 1
A) Attach two 12 side end cap (5) to rear stabilizer (4). Adjust the level of two end cap (5).
B) Attach stopper (9) to rear stabilizer (4).
C) Attach rear stabilizer (4) to under frame (1) with carriage bolt (8), curve washer (3),
spring washer (48) and acorn nut (2). Make sure the transportation wheels (7) face
outside.
Step 2
Attach pedal tube (22) and end cap (19) to front stabilizer welding (24) with Allen bolt (17)
and big flat washer (18). Insert the flat cover (16) into end cap (19).
ATTENTION: The pedal tube with magnet (25) is assembled on the left.

Master POWER-STEPPER Specifications

General

Brand	Master
Model	POWER-STEPPER
Category	Stepper Machine
Language	English
