Master POWER-STEPPER User Manual

5
EN
Parts List
NO
DESCRIPTION Q’TY
NO
DESCRIPTION
Q’TY
1 UNDER FRAME 1 29 FLAT WASHER (10) 2
2 ACORN NUT (M10) 2 30 HEX BOLT (M10*95) 1
3 CURVE WASHER (10) 2 31 BALL KNOB 1
4 REAR STABILIZER 1 32 CABLE PROTECTOR 5
5 12 SIDE END CAP 2 33 HEX BOLT (M8*20) 2
6
BIG CROSS HEAD MACHINE
SCREW (M5*12)
4 34 GRIP 2
7 TRANSPORTATION WHEELS 2 35 PLASTIC CAP (M10) 2
8 CARRIAGE BOLT (M10*95) 2 36 HANDLEBAR 1
9 STOPPER 2 37 WATER BOTTLE 1
10
CROSS HEAD MACHINE
SCREW (M6*40)
4 38 HAND PULSE (UP) 2
11 FLAT WASHER (6) 4 39 HANDLEBAR 1
12 FOOT PEDAL 1P 40 MONITOR 1
13 ALLEN BOLT (M8*40) 2 41 HAND PULSE WIRE 1
14 FLAT WASHER (8) 5 42 CARRIAGE BOLT (M8*40) 2
15 NYLON NUT (M8) 5 43
CROSS HEAD MACHINE
SCREW (M3*12)
6
16 FLAT COVER 2 44 HAND PULSE (DOWN) 2
17 ALLEN BOLT (M8*16) 5 45 GRIP 1
18 BIG FLAT WASHER (8) 4 46 PLASTIC CAP (M8) 5
19 END CAP 2 47 CURVE WASHER (8) 2
20 SLEEVE 6 48 SPRING WASHER (10) 2
21 HYDRAULIC CYLINDER 2 49 ACORN NUT (M8) 2
22 PEDAL TUBE 2 50 SPRING WASHER (6) 4
23 WATER BOTTLE FRAME 1 51 UPPER FRAME 1
24 FRONT STABILIZER WELDING 1 52 SHORT SENSOR WIRE 1
25 MAGNET 1 53 SENSOR WIRE 1
26
CROSS HEAD MACHINE
SCREW (M5*10)
2 54
BIG CROSS HEAD
MACHINE SCREW (M5*16)
2
27 SENSOR WIRE 1
28 NY LON NUT (M10) 1
