Master STAR User Manual

USING THE MANUAL COMMAND,
BRING THE MOTOR TO THE
LOW LIMIT POSITION.
OFF
SWITCH OFF
POWER SUPPLY
ON
SWITCH ON
POWER SUPPLY
WAIT
2 sec.
WITHIN
8 sec.
WAIT
2 sec.
PRESS
IN QUICK SUCCESSION
THE BUTTON
10 TIMES
DOWN
PRESS
IN QUICK SUCCESSION
THE BUTTON
2 TIMES
DOWN
x 10 TIMES
DOWN
x 2 TIMES
DOWN
PERFORM THE OPERATION WITHIN: 15 seconds
THE MOTOR OPERATES 2 SMALL
UPWARD MOVEMENTS
TO SIGNAL THE ENTRY INTO
THE TRANSMITTER MENU
PRESS
BUTTON « »
ON THE TRANSMITTER
TO BE STORED IN MEMORY
STOP
THE UPWARD MOVEMENT OF THE
MOTOR SIGNALS
THE STORAGE.
USING THE
TRANSMITTER ALREADY
IN MEMORY BRING
THE MOTOR TO THE
INTERMEDIATE POSITION.
PRESS AND HOLD
« » ON THE
TRANSMITTER ALREADY
IN MEMORY
PROG
PRESS «STOP» ON
THE NEW TRANSMITTER
TO BE STORED IN MEMORY
THE MOTOR
OPERATES
2 UPWARD
MOVEMENTS
WITHIN
8 sec.
THE UPWARD MOVE
OF THE MOTOR SIGNALS
THE STORAGE.
INTERMEDIATE
POSITION
(around half way).
THE MOTOR STARTS TO MOVE
AND STOP IN THE INTERMEDIATE
POSITION PREVIOUSLY
STORED.
WAIT
2 sec.
TO SET
THE INTERMEDIATE POSITION
PRESS AND
(holding STOP)
PRESS
STOP
UP
PRESS AND HOLD
STOP + UP
BRING THE MOTOR
TO THE DESIRED
INTERMEDIATE
POSITION
THE MOTOR STORES
THE INTERMEDIATE POSITION
AND COMMANDS 2 MOVEMENTS
ON THE OPPOSITE DIRECTIONS.
WAIT
2 sec.
08. Memorization of the first trasnmitter when the limit switches have been set using a manual command.
09. Memorization of an additional transmitter.
10. Setting the intermediate position using the command buttons.
11. Recalling the intermediate position using the command buttons.
12. Setting the intermediate position using the transmitter.
TO SET THE INTERMEDIATE
POSITION PRESS
IN QUICK
SUCCESSION THE
BUTTON
5 TIMES
UP
x 5 TIMES
UP
USING THE
MANUAL COMMAND
BRING THE MOTOR
ON THE DESIRED
INTERMEDIATE POSITION
THE MOTOR STORES
THE INTERMEDIATE POSITION
AND COMMANDS 2 MOVEMENTS
ON THE OPPOSITE DIRECTIONS.
WAIT
2 sec.
instruction guide STAR / VENUS rev01 16.04.12
