Master STONE User Manual

10
19. TILTING
This parameter allows you to select the duration of the orientation movement.
Setting 1: "Minimum time movement".
Choose this setting if the run between position 1 (Open slats) and position 2 (Close slats) is short.
The factory sets this parameter to 4 (Maximum time movement).
N° of movements Duration of movement
1
2
3
4*
Minimum
+
++
Maximum
*factory setting
18. OBSTACLE ON DOWNWARD
Necessary condition for the proper operation of this feature is the use of the offset adapter, properly installed (see section
03 "Installation of offset adapters"). When the obstacle is detected, the motor stops the manoeuvre and makes a large
upward movement to allow the obstacle to be removed. The motor is able to detect obstacles such as to stop the roller
shutter almost instantaneously, obstacles that gradually slow down the rolling shutter may not be detected.
Setting 1: "Function inactive".
Choose this setting if the roller shutter does not slide well in the guides, to prevent the motor from detecting non-existent
obstacles. In this case, the factory also recommends checking the installation of the roller shutter.
Setting 2-4: "Minimum sensitivity - average - maximum".
Choose according to the desired reactivity. The factory sets the parameter at level 3 (average sensitivity). Use level 4
(maximum sensitivity) only if the sliding of the roller shutter is optimal.
The motor is able to detect an obstacle during the upward movement. When the obstacle is detected, the motor stops
the maneuver and makes a short downward movement to don't keep the roller blind in traction.
It is possible to select the reactivity of the motor to the obstacle during the upward movement: the higher the value,
the greater the sensitivity.
The factory sets this parameter at level 3 (medium high sensitivity).
Use level 4 only if the sliding of the roller shutter is optimal.
17. OBSTACLE ON UPWARD
N° of movements
Sensibility
1
2
3
Minimum
Medium
Medium high
*factory setting
4
Maximum
*
10.1 UTILIZZANDO IL TRASMETTITORE (solo Atom e Leg)
ARCO
FLUTE, KUADRO, KORT
VISIO Other transmitters...
01. Bring the motor in an intermediate position
02. Press MENU for about 5 sec, until «rS»
appears on display
03. Press 1 time PREV / 3 times NEXT.
«13» appears on display
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press NEXT the number of times equal to
the desired setting (1 to 4)
06. Press STOP. The motor signals the new
value (1 to 4 movements)
01. Bring the motor in an intermediate position
02. Holding down STOP, press PROG for about
1 sec, until LEDs light
03. Press 1 time UP / 3 times DOWN.
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press DOWN the number of times equal to
the desired setting (1 to 4)
06. Press STOP. The motor signals the newt
value (1 to 4 movements)
01. Bring the motor in an intermediate position
02. Press MENU, «Menu rx» appears on
display
03. Press 1 time PREV / 3 times NEXT.
«13» appears on display
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press UP the number of times equal to the
desired setting (1 to 4)
06. Press STOP. The motor signals the new
value (1 to 4 movements)
See the User manual of
the transmitter at
section:
«RECEIVER MENU -
Function 13»
*factory setting
N° of movements
Setting
1
2
3
*
4
Not active function
Minimum sensitivity
Medium sensitivity
Maximum sensitivity
Other transmitters...
See the User manual of
the transmitter at
section:
«RECEIVER MENU -
Function 09»
10.1 UTILIZZANDO IL TRASMETTITORE (solo Atom e Leg)
ARCO
FLUTE, KUADRO, KORT
VISIO
01. Bring the motor in an intermediate position
02. Press MENU for about 5 sec, until «rS»
appears on display
03. Press 9 times NEXT.
«09» appears on display
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press NEXT the number of times equal to
the desired setting (1 to 4)
06. Press STOP. The motor signals the new
value (1 to 4 movements)
01. Bring the motor in an intermediate position
02. Holding down STOP, press PROG for about
1 sec, until LEDs light
03. Press 9 times DOWN.
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press DOWN the number of times equal to
the desired setting (1 to 4)
06. Press STOP. The motor signals the newt
value (1 to 4 movements)
01. Bring the motor in an intermediate position
02. Press MENU, «Menu rx» appears on
display
03. Press 9 times NEXT.
«09» appears on display
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press UP the number of times equal to the
desired setting (1 to 4)
06. Press STOP. The motor signals the new
value (1 to 4 movements)
R
MASTER uses packaging recyclable materials. Dispose materials on the proper containers, complying with the law in force in your locality.
This product may have substances that are polluting for the environment and dangerous for the health.
At the end of the product life cycle, carefully comply with the waste disposal rules. It is strictly forbidden to dispose the product on the domestic waste.
Disposal
All rights reserved. All products and technical specifications given in this document are subject to variation without notice. Unless previously and specifically authorised by the manufacturer, the device must be used
exclusively with transmitters produced by the same manufacturer.The manufacturer shall not be liable for damage resulting from improper, incorrect or unreasonable use.
ARCO
FLUTE, KUADRO, KORT
VISIO Other transmitters...
01. Bring the motor in an intermediate position
02. Press MENU for about 5 sec, until «rS»
appears on display
03. Press 1 time PREV / 2 times NEXT.
«12» appears on display
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press NEXT the number of times equal to
the desired setting (1 to 4)
06. Press STOP. The motor signals the new
value (1 to 4 movements)
01. Bring the motor in an intermediate position
02. Holding down STOP, press PROG for about
1 sec, until LEDs light
03. Press 1 time UP / 2 times DOWN.
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press DOWN the number of times equal to
the desired setting (1 to 4)
06. Press STOP. The motor signals the newt
value (1 to 4 movements)
01. Bring the motor in an intermediate position
02. Press MENU, «Menu rx» appears on
display
03. Press 1 time PREV / 2 times NEXT.
«12» appears on display
04. Press STOP. The motor signals the current
value (1 to 4 movements)
05. Press UP the number of times equal to the
desired setting (1 to 4)
06. Press STOP. The motor signals the new
value (1 to 4 movements)
See the User manual of
the transmitter at
section:
«RECEIVER MENU -
Function 12»
19.1 USING A TRANSMITTER
Command buttons
ARCO
FLUTE, KUADRO, KORT, VISIO Other transmitters...
Press a button (less than 0.5 sec), then press it
again and hold it until you reach the desired
orientation.
Use the dedicated buttons LEFT and RIGHT
orientation.
Press STOP quickly twice and hold down UP or
DOWN.
See the User manual of
your transmitter
19.2 HOW TO COMMAND THE TILTING
