Master ZEUS - Page 59

59
EN
PART LIST 2
PART NO.
DESCRIPTION
QTY
1 BIG BACK CUSHION 2
2 SEAT CUSHION 2
3 SMALL BACK CUSHION 1
4 ARM REST CUSHION 2
5
FOAM ROLLER
φ
58
*
φ
100*250
2
6
FOAM ROLLER
φ
23*
φ
70*145
8
7 HANDLE GRIP 4
8 SELECTOR SHAFT 1
9 ADJUSTABLE CYLINDER 2
10 PRESS BAR LOCK SCREW 1
11 SIT UP CUSHION 1
12 HOOK 5
13 CHAIN 2
14
PIN
φ
10*170
1
15 CABLE (MIDDLE) 1
16 CABLE (DOWN) 1
17 CABLE (UP) 1
18 BIG PIN + WASHERS + LOCK NUT M16 2
19 TRIANGULAR SCREW 1
20 QUINCUNX SCREW M10 1
21
TUBE
φ
16
1
22
SCREW M12*165 + TWO WASHERS + TWO LOCK NUTS
1
23 SCREW M10*70 + WASHER 2
24 SCREW M10*20 + WASHER 6
25 LOCK NUT M12 + WASHER 4
26 SCREW M10*80 + TWO WASHERS + LOCK NUT 1
27 SCREW M10*75 + TWO WASHERS + LOCK NUT 6
28 SCREW M10*75 + TWO WASHERS + NUT 10
29 SCREW M10*70 + TWO WASHERS + NUT 24
30 SCREW M10*35 + LOCK NUT 1
31 SCREW M10*20 + LOCK NUT 2
32 SCREW M8*45 + WASHER + LOCK NUT 6
33 SCREW M8*65 + WASHER 10
34 SCREW M8*40 + TWO WASHERS + LOCK NUT 1
35
PIN
φ
10*70
1
36 SCREW M6*16 12
37 RUBBER DONUT 2
38 SCREW M6*16 + TWO WASHERS + NUT 8
39 SCREW M8*40 + WASHER + LOCK NUT 2
40 SCREW M10*45 1
41 SCREW M10*45 + WASHER + NUT 2
42 BUFFER 3
43 SCREW M10*45 + TWO WASHERS + NUT 11
