Integrity Bath MB-80 Operating Instructions
______________________________________________________________________________________________
MB-80 Operations 2/18/13 800.798.5867
Turn On The BathAire(SM):
Turn on the BathAire
(SM)
by pushing in on the
BathAire
(SM)
On/Off Touch Pad located on the
upper right side deck of the tub. This will warm up
the environment inside the tub. You can increase
or decrease the air flow by pushing down on the
plus (+) or minus (-) section of the touch pad. If
Aromatherapy is desired place selected scent
sachet in the Aromatherapy sachet holder and
securely close the cap prior to turning on BathAire.
CAUTION: Do not remove beads from sachet.
Never place liquids in the Aromatherapy sachet
holder.
Transfer into the Tub:
To transfer the individual into the tub, pull up on
the Active Chair Release Lever while pushing the
chair into the tub using the chair armrest. Once
the chair is locked into the first position, move to
the side of the bath and pull on the Chair Handle
while lifting the Main Chair Release Lever. Pull
the chair all the way into the tub, latching into the
last rail notch. Carriers with fixed back chairs can
remain in this position.
Disengage Carrier From In Front Of Tub:
Unlock the caster brakes on the carrier and
release the Carrier Latch Pin by stepping down on
the Carrier Latch Pin Release Lever. Use the
Carrier Arm and roll the carrier out of the way so
you can close the door.
Close The Tub Door:
Lower the leg rest by lifting on the Leg Rest
Adjustment. Rotate door to closed position. With
both hands on the top of the door, align it so that it
is parallel with the black seal and seal retainer.
Push gently and evenly with both hands until the
door is all the way down and locks into position.
You will hear a definite click sound when this
happens. Rotate the Cam Arm up to lock the door
in place.
Active Chair Release
Handle
Carrier Latch Pin Release Lever
Access Cap
Speed Control
To Next Page
