Integrity Bath MB-80 Operating Instructions
______________________________________________________________________________________________
MB-80 Operations 2/18/13 800.798.5867
Chair Rail Notches:
There are four (4) Rail Notches for docking the
chair within the tub.
Remove Commode Attachment:
Move the chair forward by using the Main Chair
Release (see previous page); allowing the chair to
stop at the next rail notch. Remove the
Commode Attachment and Holder by grasping the
handle and pulling it away from the chair. For
Reclinable Back Chairs leave the chair in this rail
notch. For Fixed Back Chairs return the chair to
the last rail notch. Raise the Leg Rest to a
comfortable position for the caregiver and
individual that is being bathed.
For Chair with Reclining Back:
To recline the chair, push down on the Gas Spring
Release Lever and push the back of the chair
towards the back of the tub.
Fill The Tub:
First bring the water temperature up to normal
bath temperature by placing the shower wand
inside the bath, turned toward the side wall, then
turn on the Shower Wand Control Valve. Run the
water until it reaches the desired temperature;
adjust the water temperature between 96° to 105°
by turning the Mixing Valve toward the hot or cold
side. Turn off the Shower Wand Control Valve
and replace the Shower Wand. Close the drain by
pushing down on the Drain Open/Close Lever.
Slowly turn the Tub Fill Valve open and test the
water temperature again with your hand to make
sure it is safe and comfortable for the individual.
Check the temperature of the water by reading the
Temperature Thermometer. Adjust water
temperature following the above instructions if
needed. Fill to just below the overflow then turn
the fill valve off. Dispense Bath Oil into the water
by pushing the Bath Oil button on the side of the
tub as outlined on page 13.
Shower Wand Control
Valve
Mixing Valve
Thermometer
Tub Fill Valve
Shower
Wand
Gas Spring Release Lever
Commode Attachment
