model no. 054-0370-0 | contact us 1-800-689-9928

5. Replace the side cover onto the saw head. Rotate

the side-cover knob clockwise to slightly tighten the

side cover, but leave the bar free to move for tension

adjustment (fig. 1e).

6. Rotate the side-cover knob clockwise to completely

tighten the side cover.

fig. 1e

Side-cover knob

Side cover

OPERATING INSTRUCTIONS

WARNING!

• Always wear protective gloves when handling the bar and chain; these components are sharp and may

contain burrs.

FPO

NOTICE:

• When you first purchase your pole saw, the chain and bar will not be attached to the saw.

• The chain is correctly tensioned when there is no sag on the underside of the guide bar; the chain is snug, but can be

rotated by hand without binding. For more information on chain tensioning, see the maintenance section.

• If the chain is too tight, it will not rotate. Loosen the side cover slightly and turn the chain tensioner 1/4 turn counter-

clockwise (fig. 1f). Lift the tip of the guide bar up and retighten the side cover. Ensure that the chain can be rotated by

hand without binding.

fig. 1f

Chain tensioner

Loosen the chain tension

Wrench
