MasterCraft 054-1209-2 User Manual

30
Key #
Part #
Part Name
Quantity
31
5403290101
2-speed lever
1
32
201333
Moveable ring gear
1
33
5101820101
Planetary carrier
1
34
200072
Planetary gear
3
35
144040
Planetary carrier
1
36
5101840101
Planetary gear
3
37
201334
Fixed ring gear
1
38
221227
Clamp plate 0.5 mm
1
39
500801
Screw M3×8
2
40
504003
Spring washer
2
41
316517
Motor flange
1
42
200074
Motor gear
1
43
2500310101
Motor (550)
1
44
4408570101
Decorative cover-left
1
45
4408610101
Speed Plate
1
46
242517
Spring
1
47
3301580101
Magnetic decorative plate
1
48
258471
Magnetic block
1
49
8600840101
Spirit level
1
50
4408620101
Level cover
1
51
4408600101
Switch lever
1
52
3300150301
Switch
1
53
4404500101
Contact plate
1
54
241628
Positioning spring
2
55
202716
Gear shaft
2
56
205589
Sleeve
2
57
241635
Small spring
1
58
306172
Upper housing
1
59
250000
Thrust needle roller bearing
1
60
500001
Screw ST2.9 ×16
5
PARTS LIST
