MasterCraft 054-1245-4 User Manual

24
Key #
Part #
Part Name
Quantity
26
502000
Nut M6
1
27
214907
Pinion
1
28
520027
Bearing 6000
1
29
224306
Bearing clamp B
1
30
6516400812
Screw M4×8
2
31
6100740101
Drive shaft
1
32
4600750101
Rubber drive link
1
33
500806
Screw ST2.9×8
2
34
5101920101
Drive link tray connector
1
35
5610310101
Fan
1
36
6511500812
Screw M5×8
2
37
5403430101
Spring washer M5
2
38
5403440101
Motor flange
1
39
5800480301
Auxiliary handle
1
40
6100750101
Pin
1
41
4408950101
Switch button
1
42
4408960101
Switch lock button
1
43
5501220101
Spring
1
44
4408980101
Block
1
45
6597292523
Screw ST2.9×25
2
46
2700280101
Switch
1
47
5501230101
Switch spring
1
48
4408970101
Switch slide
1
49
6597391923
Screw ST3.9×19
6
50
4301680201
Right housing
1
51
4404500101
Large pole plate
1
52
3601820101
Button housing
1
53
2000290201
Battery pack
1
54
2500240101
Motor
1
55
4301670201
Left housing
1
56
4406640101
Décor board
1
57
4404510101
Small pole plate
1
PARTS LIST

MasterCraft 054-1245-4 Specifications

General

Brand	MasterCraft
Model	054-1245-4
Category	Grinder
Language	English
