18
model no. 054-1332-6 | contact us 1-800-689-9928
BIT STORAGE (fig 7)
When not in use, the bits that are provided with the
cordless drill/driver may be stored on either side of
the cordless drill/driver by snapping the bit into place
in the bit clip.
INSTALLING A BIT (fig 8a)
1. Lock the trigger switch by placing the direction-of-
rotation selector in the OFF (centre) position.
2. Rotate the chuck in the “OPEN” direction to release
the jaws of the chuck on the bit.
3. Insert the drill bit.
4. Rotate the chuck in the “GRIP” direction to tighten the
jaws of the chuck securely on the bit.
REMOVING A BIT (fig 8a)
1. Lock the trigger switch by placing the direction-of
rotation selector in the OFF (centre) position.
2. Rotate the chuck in the “OPEN” direction to release
the jaws of the chuck on the bit.
3. Remove the drill bit.
OPERATING INSTRUCTIONS
fig 7
Bit Clip
fig 8a
Open
Grip
Keyless
Chuck
fig 8b
WARNING!
• Be sure to insert the drill bit straight into the jaws of the chuck. Do not tighten the jaws of the chuck with the drill bit
inserted at an angle (fig 8b). Doing so could cause the drill bit to be thrown from the drill/driver, which could result in
possible serious personal injury or damage to the chuck.
• Use protective gloves when removing the bit from the tool, or first allow the bit to cool down. The bit may be hot after
prolonged use.
