20
model no. 054-1332-6 | contact us 1-800-689-9928
DRILLING MODE OPERATION
For drilling in wood, use twist bits, spade bits, power auger bits or hole saws.
1. When drilling “through” holes, place a block of wood behind the workpiece to prevent ragged or splintered
edges on the back side of the hole.
2. Select the desired speed to match the planned operation.
3. Begin drilling at a very low speed to prevent the bit from slipping off the starting point, and then increase
the speed as the drill bit bites into the material.
4. If the drill/driver stalls, it is usually because it is being overloaded. Release the trigger switch immediately,
reverse the direction of rotation and gently squeeze the trigger switch to remove the bit from the workpiece.
Investigate and correct the cause of stalling before resuming work.
5. Keep the motor running when pulling the bit back out of the drilled hole. This will prevent jamming.
For drilling in metal, use high-speed steel twist drill bits.
1. Use light oil on the drill bit to keep it from overheating; the oil will prolong the life of the bit and increase
the drilling action.
2. When drilling a large hole, first use a smaller bit to drill a small pilot hole to prevent the larger bit from
slipping.
3. Select the desired speed to match the planned operation. Begin drilling at a very low speed to prevent
the bit from slipping off the starting point. Maintain a speed and pressure that allows cutting without
overheating the bit.
4. If the drill/driver stalls, it is usually because it is being overloaded. Release the trigger switch immediately,
reverse the direction of rotation and gently squeeze the trigger switch to remove the bit from the workpiece.
Investigate and correct the cause of stalling before resuming work.
5. Keep the motor running when pulling the bit back out of drilled hole. This will prevent jamming.
SCREWDRIVER OPERATION
1. Select the desired speed/torque range to match the planned operation.
2. Attach the desired fastener accessory into the chuck.
3. Make a few practice runs in a scrap piece before working.
OPERATING INSTRUCTIONS
