22
model no. 054-1332-6 | contact us 1-800-689-9928
CHUCK REMOVAL (fig 10)
The chuck can be removed and replaced with a
new one.
1. Lock the trigger switch by placing the direction-of-
rotation selector in the centre position.
2. Open the chuck jaws. Using a screwdriver, remove
the chuck screw by turning it clockwise,
3. Insert a 5/16-in. or larger hex key into the chuck of
the drill/driver and tighten the chuck jaws securely.
4. Tap the hex key sharply with a mallet in a counter-
clockwise direction. This will loosen the chuck for
easy removal.
5. Attach a new chuck to the spindle and tighten the
chuck screw.
MAINTENANCE
fig 10
Mallet
Hex Wrench
Chuck Jaws
